RS-232 INTERFACE 7 - 15

Host Serial Response Time-out

This parameter specifies how long the linear imager scanner waits for an ACK, NAK, ENQ, XON, or CTS

before determining that a transmission error occurred.

*Minimum: 2 sec

Low: 2.5 sec

Medium: 5 sec

High: 7.5 sec

Maximum: 9.9 sec
