11 - 60 LI4278 Product Reference Guide

Inverse 1D

Parameter # 586

This parameter sets the 1D inverse decoder setting. Options are:

•

Regular Only - the linear imager scanner decodes regular 1D bar codes only.

•

Inverse Only - the linear imager scanner decodes inverse 1D bar codes only.

•

Inverse Autodetect - the linear imager scanner decodes both regular and inverse 1D bar codes.

*Regular

(00h)

Inverse Only

(01h)

Inverse Autodetect

(02h)
