Zebra LI4278 - Code Lengths

To Next Page

To Previous Page

ADVANCED DATA FORMATTING 12 - 15

Code Lengths

Scan these bar codes to define the number of characters the selected code type must contain. Select one

length per rule only. Do not select any code length to select code types of any length.

1 Character

2 Characters

3 Characters

4 Characters

5 Characters

6 Characters
