ADVANCED DATA FORMATTING 12 - 11

Criteria

Code Types

Scan the bar codes for all codes to be affected by the rule. Scan the codes prior to selecting other criteria. To

select all code types, do not scan any code type

Code 39

Codabar

GS1 DataBar-14

GS1 DataBar Limited

GS1 DataBar Expanded

Code 128

D 2 OF 5
