8 - 6 LI4278 Product Reference Guide

USB Device Type (continued)

Symbol Native API (SNAPI) Status Handshaking

After selecting a SNAPI interface as the USB device type, select whether to enable or disable status

handshaking.

USB CDC Host

Symbol Native API (SNAPI) without Imaging Interface

NOTE The CR0078-P cradle is required for SNAPI.

*Enable SNAPI Status Handshaking

Disable SNAPI Status Handshaking
