1 - 4 LI4278 Product Reference Guide

CR0078-S/CR0008-S Series Cradle

Figure 1-3

CR0078-S/CR0008-S Series Cradle Front View

Pairing

Bar Code

(CR0078-S only)

Latch

Charging/

Communications

Contacts

Cradle Power

LED

Convertible

Mount Hook

(cradle serial #)
