Zebra LI4278 Product Reference Guide

5 - 10 LI4278 Product Reference Guide
Hands-Free Trigger Mode
Parameter # 630
In hands-free mode, the linear imager scanner automatically triggers when presented with a bar code. Lifting
the linear imager scanner causes it to behave according to the setting of the Hand-Held Trigger Mode on page
5-9.
If you select Disable Hands-Free Mode, the linear imager scanner behaves according to the setting of the
Hand-Held Trigger Mode regardless of whether it is hand-held or on a counter top.
Low Power Mode
Parameter # 128
If enabled, the linear imager scanner enters a low power consumption mode after Time Delay to Low Power
Mode has expired, in which the LEDs turn off in order to conserve energy and prolong the life of the scanner.
The linear imager scanner wakes when it senses a trigger pull or when the host attempts to communicate.
If disabled, power remains on after each decode attempt.
NOTE The CR0078-P cradle is required for Hands-Free mode.
*Enable Hands-Free Mode
(01h)
Disable Hands-Free Mode
(00h)
NOTE The linear imager scanner does not go into low power mode when it is seated in the cradle.
Disable Low Power Mode
(00h)
*Enable Low Power Mode
(01h)

Zebra LI4278 Specifications

General

Wavelength	617 nm
Read rate (max)	547 reads/s
Decoding standards	UPC/EAN, UPC-A, UPC-E, UPC-E1, EAN-8/JAN 8, EAN-13/JAN 13, Bookland EAN, Bookland ISBN, UCC Coupon, ISBT 128, Code 39, Code 93, Matrix 2/5, Interleavd 2/5, Discrete 2/5, Codabar, MSI Chinese 2/5, GS1
Pitch reading angle	-65 - 65 °
Light levels (direct sunlight)	0 - 108000 lx
Bluetooth	Yes
Bluetooth version	2.1+EDR
Standard interfaces	USB, RS-232, RS-485
Operating time	4320 min
Maximum operating distance	100 m
Certification	FCC, ICES, IEC, RoHS, EN, UL
Product color	Black
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 85 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	186 mm
Width	70 mm
Height	98 mm
Weight	224 g
