FN1 Substitution

When enabled, the linear imager scanner replaces FN1 characters in an EAN128 bar code with a keystroke

chosen by the user (see FN1 Substitution Values on page 5-21).

Send Make and Break

When enabled, the scan codes for releasing a key are not sent.

Enable FN1 Substitution

*Disable FN1 Substitution

*Send Make and Break Scan Codes

Send Make Scan Code Only
