ADVANCED DATA FORMATTING 12 - 45

Beeps

Select a beep sequence for each ADF rule.

Send Keystroke (Control Characters and Keyboard Characters)

Control Characters

Scan a Send bar code for the keystroke to send.

Beep Once

Beep Twice

Beep Three Times

Send Control 2

Send Control A

Send Control B
