Zebra LI4278 - Decoding Illumination

To Next Page

To Previous Page

USER PREFERENCES & MISCELLANEOUS SCANNER OPTIONS 5 - 17

Decoding Illumination

Parameter # 298

Scanning Enable Decoding Illumination enables LED Illumination and usually results in superior images and

reading ranges. Scanning Disable Decoding Illumination disables LED illumination.

*Enable Decoding Illumination

(01h)

Disable Decoding Illumination

(00h)
