12 - 82 LI4278 Product Reference Guide

Send Graphic User Interface (GUI) Characters

The Send Graphic User Interface Character actions taps the specified key while holding the System

Dependent Graphic User Interface (GUI) Key. The definition of the Graphic User Interface key depends on the

attached system.

Send GUI 0

Send GUI 1

Send GUI 2

Send GUI 3

Send GUI 4

Send GUI 5
