Zebra LI4278 Product Reference Guide

USER PREFERENCES & MISCELLANEOUS SCANNER OPTIONS 5 - 9
Beeper Duration
Parameter # 628
To select the duration for the beeper, scan one of the following bar codes.
Hand-Held Trigger Mode
Parameter # 138
Select one of the following trigger modes for the linear imager scanner:
• Standard (Level) - A trigger pull activates decode processing. Decode processing continues until the bar
code decodes, you release the trigger, or the Decode Session Timeout occurs.
• Auto Aim - This trigger mode projects the red illumination when you lift the linear imager scanner. A
trigger pull activates decode processing. After 2 seconds of inactivity the aiming pattern shuts off.
Short
(00h)
*Medium
(01h)
Long
(02h)
*Standard (Level)
(00h)
Auto Aim
(09h)

Zebra LI4278 Specifications

General

Wavelength	617 nm
Read rate (max)	547 reads/s
Decoding standards	UPC/EAN, UPC-A, UPC-E, UPC-E1, EAN-8/JAN 8, EAN-13/JAN 13, Bookland EAN, Bookland ISBN, UCC Coupon, ISBT 128, Code 39, Code 93, Matrix 2/5, Interleavd 2/5, Discrete 2/5, Codabar, MSI Chinese 2/5, GS1
Pitch reading angle	-65 - 65 °
Light levels (direct sunlight)	0 - 108000 lx
Bluetooth	Yes
Bluetooth version	2.1+EDR
Standard interfaces	USB, RS-232, RS-485
Operating time	4320 min
Maximum operating distance	100 m
Certification	FCC, ICES, IEC, RoHS, EN, UL
Product color	Black
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 85 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	186 mm
Width	70 mm
Height	98 mm
Weight	224 g
