Zebra LI4278 - USB Host Parameters; USB Device Type

To Next Page

To Previous Page

USB INTERFACE 8 - 5

USB Host Parameters

USB Device Type

Select the desired USB device type.

NOTES 1. When changing USB Device Types, the cradle automatically restarts. The linear imager scanner issues

a disconnect-reconnect beep sequence.

2. The USB CDC host selection is only supported when the scanner is paired with the CR0078-P

(presentation), and CR0078-S (standard) cradles.

*HID Keyboard Emulation

IBM Table Top USB

IBM Hand-Held USB

USB OPOS Handheld

Simple COM Port Emulation
