RS-232 INTERFACE 7 - 7

RS-232 Host Types (continued)

Omron

OPOS/JPOS

Fujitsu RS-232

CUTE

NOTE The CUTE host disables all parameter scanning, including set defaults. If the CUTE parameter is

inadvertently selected, scan *Enable Parameter Bar Code Scanning (01h) on page 5-5, then change the

host selection.
