USB INTERFACE 8 - 3
To connect the USB interface:
1. Attach the modular connector of the USB interface cable to the host port on the bottom of the linear imager
scanner cradle (see Connecting the CR0078-S/CR0008-S Series Cradle on page 1-8 or Connecting the
CR0078-P Series Cradle on page 1-9).
2. Plug the series A connector in the USB host or hub, or plug the Plus Power connector in an available port
of the IBM SurePOS terminal.
3. Select the USB device type by scanning the appropriate bar code from USB Device Type on page 8-5.
4. On first installation when using Windows, the software prompts to select or install the Human Interface
Device driver. To install this driver, provided by Windows, click Next through all the choices and click
Finished on the last choice. The cradle powers up during this installation.
5. To modify any other parameter options, scan the appropriate bar codes in this chapter.
If problems occur with the system, see Troubleshooting on page 3-4.
NOTE Interface cables vary depending on configuration. The connectors illustrated in Figure 8-1 are examples
only. The connectors may be different than those illustrated, but the steps to connect the linear imager
scanner cradle remain the same. Ensure you use the matching cable for the appropriate cradle.
