11 - 10 LI4278 Product Reference Guide

Decode UPC/EAN/JAN Supplementals (continued)

Decode UPC/EAN/JAN Only With Supplementals

(01h)

*Ignore Supplementals

(00h)

Autodiscriminate UPC/EAN/JAN Supplementals

(02h)

Enable 378/379 Supplemental Mode

(04h)

Enable 978/979 Supplemental Mode

(05h)

Enable 977 Supplemental Mode

(07h)
