SYMBOLOGIES 11 - 63

GS1 DataBar Limited Security Level (continued)

GS1 DataBar Limited Security Level 1

(01h)

GS1 DataBar Limited Security Level 2

(02h)

*GS1 DataBar Limited Security Level 3

(03h)

GS1 DataBar Limited Security Level 4

(04h)
