ADVANCED DATA FORMATTING 12 - 73

Send Keypad Characters (continued)

Send Home Key

Send Enter Key

Send Escape Key

Send Up Arrow Key

Send Down Arrow Key

Send Left Arrow Key

Send Right Arrow Key
