ASCII CHARACTER SETS F - 7
Table F-3
Misc. Key Standard Default Table
Misc. Key Keystroke
3001 PA 1
3002 PA 2
3003 CMD 1
3004 CMD 2
3005 CMD 3
3006 CMD 4
3007 CMD 5
3008 CMD 6
3009 CMD 7
3010 CMD 8
3011 CMD 9
3012 CMD 10
3013 CMD 11
3014 CMD 12
3015 CMD 13
3016 CMD 14
Table F-4
GUI Shift Keys
Other Value Keystroke
3048 GUI 0
3049 GUI 1
3050 GUI 2
3051 GUI 3
3052 GUI 4
3053 GUI 5
3054 GUI 6
3055 GUI 7
3056 GUI 8
3057 GUI 9
The Apple
iMac keyboard has an apple key on either side of the space bar. Windows-based
systems have a GUI key to the left of the left ALT key, and to the right of the right ALT key.

Table of Contents

Other manuals for Zebra LI4278

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Zebra LI4278 and is the answer not in the manual?

Zebra LI4278 Specifications

General IconGeneral
Wavelength617 nm
Read rate (max)547 reads/s
Decoding standardsUPC/EAN, UPC-A, UPC-E, UPC-E1, EAN-8/JAN 8, EAN-13/JAN 13, Bookland EAN, Bookland ISBN, UCC Coupon, ISBT 128, Code 39, Code 93, Matrix 2/5, Interleavd 2/5, Discrete 2/5, Codabar, MSI Chinese 2/5, GS1
Pitch reading angle-65 - 65 °
Light levels (direct sunlight)0 - 108000 lx
BluetoothYes
Bluetooth version2.1+EDR
Standard interfacesUSB, RS-232, RS-485
Operating time4320 min
Maximum operating distance100 m
CertificationFCC, ICES, IEC, RoHS, EN, UL
Product colorBlack
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)0 - 50 °C
Operating relative humidity (H-H)5 - 85 %
Harmonized System (HS) code84716070
Weight and Dimensions IconWeight and Dimensions
Depth186 mm
Width70 mm
Height98 mm
Weight224 g
