3 - 12 LI4278 Product Reference Guide

Charging Temperature 32° to 104° F (0° to 40° C) nominal, 41° to 95° F (5° to 35° C) ideal

Humidity 5% to 95% (non-condensing)

Accessories

Power Supplies Power supply is required.

Table 3-4

Technical Specifications - CR0078-P Cradle (Continued)

Item Description
