RADIO COMMUNICATIONS 4 - 29

Batch Mode (continued)

*Normal

(00h)

Out of Range Batch Mode

(01h)

Standard Batch Mode

(02h)

Cradle Contact Batch Mode

(03h)

Enter Batch Mode

Send Batch Data
