Zebra MC67 Integrator Guide

A - 2 MC67 Integrator Guide
Keypad Options MC67NA Base Model : numeric, QWERTY, or Calculator DSD
MC67NA : Numeric, QWERTY, AZERTY, QWERTZ, Direct Store Delivery
(DSD) or Personal Information Manager (PIM)
MC67ND : Numeric, QWERTY, AZERTY, QWERTZ or DSD.
Audio Dual microphone support with noise cancellation; vibrate alert; speaker;
Bluetooth headset
Performance Characteristics
CPU MC67NA Base Model : Dual core 800 MHz OMAP 4 processor
MC67NA : Dual-core 1 GHz OMAP 4 processor
MC67ND : Dual-core 1 GHz OMAP 4 processor
Operating System
Microsoft
®
Embedded Handheld 6.5.3 Professional
Memory
MC67NA Base Model :512 MB RAM/2 GB Flash
MC67NA : 512 MB Random Access Memory (RAM)/2 GB Flash or 1 GB
RAM/8 GB Flash
MC67ND : 512 MB Random Access Memory (RAM)/2 GB Flash
Output Power USB - 5 VDC @ 300 mA max.
User Environment
Operating Temperature -20 °C to 50 °C (-4 °F to 122 °F)
Storage Temperature -40 °C to 70 °C (-40 °F to 158 °F)
Charging Temperature 0 °C to 40 °C (32 °F to 104 °F)
Humidity 5 to 95% non-condensing
Drop Specification
MC67NA Base Model : Multiple 1.8 m (6 ft.) drops per MIL-STD 810G
MC67NA : Multiple 2.4 meter (8 ft.) drops per MIL-STD 810G; 1.8 m (6 ft.)
drops across operating temperature per MIL-STD 810G.
MC67ND : Multiple 2.4 meter (8 ft.) drops per MIL-STD 810G; 1.8 m (6 ft.)
drops across operating temperature per MIL-STD 810G.
Tumble 1,000 0.5 meter (1.6 ft.) tumbles (2,000 drops) at room temperature; per
applicable IEC tumble specifications
Electrostatic Discharge (ESD) +/-15kVdc air discharge, +/-8kVdc direct discharge, +/-8kVdc indirect
discharge
Sealing
MC67NA Base Model : IP64 per IEC specification.
MC67NA : IP65 and IP67 per IEC specification.
MC67ND : IP65 and IP67 per IEC specification.
Vibration 4 g’s PK Sine (5 Hz to 2 kHz); 0.04g2/Hz Random (20 Hz to 2 kHz); 60
minute duration per axis, 3 axis
Thermal Shock -40° C to 70° C (-40° F to 158° F) rapid transition
Table A-1 MC67 Technical Specifications (Continued)
Item Description

Zebra MC67 Specifications

General

Display diagonal	3.5 \
Display resolution	640 x 480 pixels
Display number of colors	-
Flash memory	2 GB
Internal memory	0.512 GB
Internal memory type	RAM
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Processor family	Instruments OMAP
Processor frequency	0.8 GHz
Processor manufacturer	Texas Instruments
USB 2.0 ports quantity	1
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Battery capacity	3600 mAh
Data network	4G, HSPA+
Wi-Fi standards	802.11a, 802.11b, 802.11g
Product color	Black
Keyboard layout	QWERTY
Operating system installed	Windows Mobile 6.5

Weight and Dimensions

Depth	33.5 mm
Width	77 mm
Height	162.2 mm
Weight	385 g
