Zebra MC67 Integrator Guide

Getting Started 1 - 3
Figure 1-2 Insert microSD Card in Holder
7. Close the card holder door and push down until it is securely into place.
8. If installing a SIM card, proceed to Installing the SIM Card.
9. Close SIM card holder door and slide down until it locks into place.
10. Close rubber access door.
Installing the SIM Card
GSM phone service requires a Subscriber Identification Module (SIM) card. Obtain the card from the your
service provider. The card fits into the MC67 and can contain the following information:
• Mobile phone service provider account details.
• Information regarding service access and preferences.
• Contact information, which can be moved to Contacts on the MC67.
• Any additional services to which you have subscribed.
To install the SIM card:
1. Lift rubber access door.
2. Slide the SIM card holder up to unlock.
3. Lift the SIM card holder door.
microSD card
Holding tab
NOTE The MC67 does not support copying multiple contacts to some SIM cards. If an error message appears,
see Chapter 7, Maintenance & Troubleshooting for more information.
GSM/UMTS networks only.
NOTE For more information about SIM cards, refer to the service provider's documentation.

Zebra MC67 Specifications

General

Display diagonal	3.5 \
Display resolution	640 x 480 pixels
Display number of colors	-
Flash memory	2 GB
Internal memory	0.512 GB
Internal memory type	RAM
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Processor family	Instruments OMAP
Processor frequency	0.8 GHz
Processor manufacturer	Texas Instruments
USB 2.0 ports quantity	1
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Battery capacity	3600 mAh
Data network	4G, HSPA+
Wi-Fi standards	802.11a, 802.11b, 802.11g
Product color	Black
Keyboard layout	QWERTY
Operating system installed	Windows Mobile 6.5

Weight and Dimensions

Depth	33.5 mm
Width	77 mm
Height	162.2 mm
Weight	385 g
