1 - 4 MC67 Integrator Guide
Figure 1-3 Lifting the SIM Cover
4. Insert the SIM card, as shown in Figure 1-4 ensuring that the card slides into the holding tabs on each side
of the door.
Figure 1-4 Inserting the SIM Card
5. Close SIM card holder door and slide down to lock into place.
6. Close the rubber access door.
7. Install the battery.
Installing the Battery
To install the battery.
1. Insert the battery, bottom first, into the battery compartment in the back of the MC67.
2. Press the battery down into the battery compartment until the battery release latch snaps (2-clicks) into
place. The MC67 turns on if the battery is properly charged.
3. Replace the handstrap.
