Zebra MC67 - Charging the Spare Battery; Battery Charging Indicators

2 - 4 MC67 Integrator Guide
Figure 2-2 MC67 Battery Charging
Charging the Spare Battery
Figure 2-3 Spare Battery Charging
Battery Charging Indicators
The Single Slot USB cradle charges the MC67’s main battery and a spare battery simultaneously.
Charge Status LED
Spare Battery
Spare Battery
Charging LED
