Zebra MC67 Integrator Guide

A - 8 MC67 Integrator Guide
Table A-3 SE4500-SR Decode Distances
Symbol Density/
Bar Code Type
Bar Code Content/
Contrast
Note 2
Typical Working Ranges
Near Far
5.0 mil
Code 39
ABCDEFGH
80% MRD
2.1 in
5.33 cm
7.5 in
19.05 cm
6.67 mil
PDF417
4 Col, 20 Rows
80% MRD
3.4 in
8.64 cm
7.1 in
18.03 cm
7.5 mil
Code 39
ABCDEF
80% MRD
Note 1 10.6 in
26.92 cm
10 mil
PDF417
3 Col, 17 Rows
80% MRD
Note 1 10.1 in
25.65 cm
13 mil
UPC-A
012345678905
80% MRD
1.6 in
5.08 cm
15.5 in
39.37 cm
15 mil
PDF417
80% MRD Note 1 14.7 in
37.34 cm
15 mil
Data Matrix
18 x 18 Modules
80% MRD
2.8 in
7.11 cm
12.4 in
31.50 cm
20 mil
Code 39
123
80% MRD
Note 1 24.7 in
62.74 cm
Notes:
1. Near distances are field-of-view (FOV) limited.
2. Contrast is measured as Mean Reflective Difference (MRD) at 670 nm.
3. Working range specifications at temperature = 23°C, pitch=18°, roll=0°, skew=0°, photographic quality,
ambient light ~30 ft-c, humidity 45-70% RH.
4. Distances measured from front edge of scan engine chassis.

Zebra MC67 Specifications

General

Display diagonal	3.5 \
Display resolution	640 x 480 pixels
Display number of colors	-
Flash memory	2 GB
Internal memory	0.512 GB
Internal memory type	RAM
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Processor family	Instruments OMAP
Processor frequency	0.8 GHz
Processor manufacturer	Texas Instruments
USB 2.0 ports quantity	1
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Battery capacity	3600 mAh
Data network	4G, HSPA+
Wi-Fi standards	802.11a, 802.11b, 802.11g
Product color	Black
Keyboard layout	QWERTY
Operating system installed	Windows Mobile 6.5

Weight and Dimensions

Depth	33.5 mm
Width	77 mm
Height	162.2 mm
Weight	385 g
