Zebra MC67 - Locking the MC67

Accessories 2 - 17
3. Swing the four slot cradle down onto the mounting bracket and align the mounting screws so that they fit
into the screw slots.
Figure 2-19 Wall Mount Bracket
4. Tighten the mounting screws to secure the four slot cradle to the bracket.
Figure 2-20 Mounting Screws
5. Connect power (see Figure 2-16 on page 2-15). The power supply should be located in the power supply
well.
Wall Mount
Bracket
Screw Slots
Power Supply
Well
