DI3 See selection DI1.3
DI4 See selection DI1.4
DI5 See selection DI1.5
START Timer reset at start. Start signal source is selected by
parameter 1902 TIMER START.
6
START (INV) Time reset at start (inverted), ie, timer is reset when start
signal is deactivated. Start signal source is selected by
parameter 1902 TIMER START.
7
RESET External reset, eg, reset through fieldbus 8
1904 COUNTER
ENABLE
Selects the source for the counter enable signal. DISABLE
D
DI1(INV) Counter enable signal through inverted digital input DI1. 0 =
active, 1 = inactive.
-1
DI2(INV) See selection DI1(INV).-2
DI3(INV) See selection DI1(INV).-3
DI4(INV) See selection DI1(INV).-4
DI5(INV) See selection DI1(INV).-5
DISABLED No counter enable 0
DI1 Counter enable signal through digital input DI1. 1 = active, 0
= inactive.
1
DI2 See selection DI1.2
DI3 See selection DI1.3
DI4 See selection DI1.4
DI5 See selection DI1.5
ENABLED Counter enabled 6
1905 COUNTER
LIMIT
Defines the counter limit. 1000
0…65535 Limit value 1 = 1
1906 COUNTER
INPUT
Selects the input signal source for the counter. PLS IN(DI
5)
PLS IN(DI 5) Digital input DI5 pulses. When a pulse is detected, the
counter value increases by 1.
1
ENC W/O DIR Encoder pulse edges. When a rising or a falling edge is
detected, the counter value increases by 1.
2
ENC WITH DIR Encoder pulse edges. The direction of rotation is taken into
account. When a rising or a falling edge is detected and the
direction of rotation is forward, the counter value increases
by 1. When the direction of rotation is reverse, the counter
value decreases by 1.
3
