Actual signals and parameters 219
FILTERED DI5 Filtered digital input DI5 pulses. When a pulse is detected,
the counter value increases by 1.
Note: Due to filtering, the maximum input signal frequency
is 50 Hz.
4
1907 COUNTER
RESET
Selects the source for the counter reset signal. NOT SEL
DI1(INV) Counter reset through inverted digital input DI1. 0 = active, 1
= inactive.
-1
DI2(INV) See selection DI1(INV).-2
DI3(INV) See selection DI1(INV).-3
DI4(INV) See selection DI1(INV).-4
DI5(INV) See selection DI1(INV).-5
NOT SEL No reset signal 0
DI1 Counter reset through digital input DI1. 1 = active, 0 =
inactive.
1
DI2 See selection DI1.2
DI3 See selection DI1.3
DI4 See selection DI1.4
DI5 See selection DI1.5
AT LIMIT Reset at the limit defined by parameter 1905 COUNTER
LIMIT
6
STRT/STP
CMD
Counter reset at start/stop command. Source for the
start/stop is selected by parameter 1911 CNTR S/S
COMMAND.
7
S/S CMD(INV) Counter reset at start/stop command (inverted), ie, counter
is reset when start/stop command is deactivated. Start
signal source is selected by parameter 1902 TIMER
START.
8
RESET Reset enabled 9
All parameters
No. Name/Value Description Def/FbEq
