Actual signals and parameters 305
ENTER
SETPNT
State change when drive output frequency/speed enters the
reference area (ie, the difference is less than or equal to 4%
of the maximum reference).
51
AT SETPOINT State change when drive output frequency/speed equals the
reference value (= is within tolerance limits, ie, the error is
less than or equal to 1% of the maximum reference).
52
AI1 L1 & DI5 State change when AI1 value < par. 8412 SEQ VAL 1 LOW
and when DI5 is active.
53
AI2 L2 & DI5 State change when AI2 value < par. 8414 SEQ VAL 2 LOW
value and when DI5 is active.
54
AI1 H1 & DI5 State change when AI1 value > par. 8411 SEQ VAL 1 HIGH
value and when DI5 is active.
55
AI2 H2 & DI5 State change when AI2 value > par. 8413 SEQ VAL 2 HIGH
value and when DI5 is active.
56
AI1 L1 & DI4 State change when AI1 value < par. 8412 SEQ VAL 1 LOW
value and when DI4 is active.
57
AI2 L2 & DI4 State change when AI2 value < par. 8414 SEQ VAL 2 LOW
value and when DI4 is active.
58
AI1 H1 & DI4 State change when AI1 value > par. 8411 SEQ VAL 1 HIGH
value and when DI4 is active.
59
AI2 H2 & DI4 State change when AI2 value > par. 8413 SEQ VAL 2 HIGH
value and when DI4 is active.
60
DLY AND DI1 State change when delay time defined by parameter 8424
ST1 CHANGE DLY has elapsed and DI1 is active.
61
DLY AND DI2 State change when delay time defined by parameter 8424
ST1 CHANGE DLY has elapsed and DI2 is active.
62
DLY AND DI3 State change when delay time defined by parameter 8424
ST1 CHANGE DLY has elapsed and DI3 is active.
63
DLY AND DI4 State change when delay time defined by parameter 8424
ST1 CHANGE DLY has elapsed and DI4 is active.
64
DLY AND DI5 State change when delay time defined by parameter 8424
ST1 CHANGE DLY has elapsed and DI5 is active.
65
DLY & AI2 H2 State change when delay time defined by parameter 8424
ST1 CHANGE DLY has elapsed and AI2 value > par. 8413
SEQ VAL 2 HIGH value.
66
DLY & AI2 L2 State change when delay time defined by parameter 8424
ST1 CHANGE DLY has elapsed and AI2 value < par. 8414
SEQ VAL 2 LOW value.
67
DLY & AI1 H1 State change when delay time defined by parameter 8424
ST1 CHANGE DLY has elapsed and AI1 value > par. 8411
SEQ VAL 1 HIGH value.
68
All parameters
No. Name/Value Description Def/FbEq
