ABB ACS560 - Page 139

Control macros 139
Parameter Settings
To enable the SPFC macro, navigate to

• Main menu  Connection macro  SPFC
or
• Main menu
 Complete parameter list parameter 96.04 Macro select 
[18] SPFC.
The following default values are used for the SPFC macro:
No. Value No. Value
10.24
7=Running
22.73
0 = Not used
10.27
45 = PFC1
22.74
0 = Not used
10.30
46 = PFC2
23.11
6 = DI5
12.17
0
28.11
1 = AI1 scaled
12.20
50.0
28.15
16 = PID
13.12
2 = Output frequency
28.22
0 = Always off
13.18
50.0
28.23
0 = Always off
19.11
5 = DI3
28.71
0 = Acc/Dec time 1
19.17
0 = No
30.11
-1500 rpm
20.01
1 = In1 Start
31.01
1 = Inactive (true)
20.03
2 = DI1
31.02
0 = Fault
20.04
0 = Always off
40.07
2 = On when drive running
20.05
0 = Always off
40.16
11 = AI1 percent
20.06
1 = In1 Start
40.17
0 = Not selected
20.08
7 = DI6
40.19
0 = Not selected
20.09
0 = Always off
40.20
0 = Not selected
20.12
3 = DI2
40.32
2.50
20.19
1 = Selected
40.33
3.0
21.03
0 = Coast
76.21
2=SPFC
22.11
16 = PID
76.25
2
22.18
16 = PID
76.27
2
22.22
0 = Always off
99.04
0 = Scalar
22.23
0 = Always off
