Parameters 215
Sunday Time period 3 starts on Sunday. 7
36.14 Stop day3 Defines the week day on which time period 3 ends.
Monday Time period 3 ends on Monday. 1
Tuesday Time period 3 ends on Tuesday. 2
Wednesday Time period 3 ends on Wednesday. 3
Thursday Time period 3 ends on Thursday. 4
Friday Time period 3 ends on Friday. 5
Saturday Time period 3 ends on Saturday. 6
Sunday Time period 3 ends on Sunday. 7
36.15 Start time4 Defines the start time for time period 4.
00:00:00 …
24:00:00
Start time for time period 4. 1 = 1 s
(24:00:00 =
86400)
36.16 Stop time4 Defines the stop time for time period 4.
00:00:00 …
24:00:00
Stop time for time period 4. 1 = 1 s
(24:00:00 =
86400)
36.17 Start day4 Defines the week day on which time period 4 begins.
Monday Time period 4 starts on Monday. 1
Tuesday Time period 4 starts on Tuesday. 2
Wednesday Time period 4 starts on Wednesday. 3
Thursday Time period 4 starts on Thursday. 4
Friday Time period 4 starts on Friday. 5
Saturday Time period 4 starts on Saturday. 6
Sunday Time period 4 starts on Sunday. 7
36.18 Stop day4 Defines the week day on which time period 4 ends.
Monday Time period 4 ends on Monday. 1
Tuesday Time period 4 ends on Tuesday. 2
Wednesday Time period 4 ends on Wednesday. 3
Thursday Time period 4 ends on Thursday. 4
Friday Time period 4 ends on Friday. 5
Saturday Time period 4 ends on Saturday. 6
Sunday Time period 4 ends on Sunday. 7
36.19 Boost signal Boosting can be used to extend the timer enable signal for
the time defined by parameter 36.20 Boost time. The boost
time starts when the boost signal changes state from 1 to 0.
DI1 Digital input DI1 (as indicated by 02.01 DI status, bit 0). 1073742337
DI2 Digital input DI2 (as indicated by 02.01 DI status, bit 1). 1073807873
DI3 Digital input DI3 (as indicated by 02.01 DI status, bit 2). 1073873409
DI4 Digital input DI4 (as indicated by 02.01 DI status, bit 3). 1073938945
DI5 Digital input DI5 (as indicated by 02.01 DI status, bit 4). 1074004481
DI6 Digital input DI6 (as indicated by 02.01 DI status, bit 5). 1074070017
No. Name/Value Description FbEq
