216 Parameters
DIO4 Digital input/output DIO4 (as indicated by 02.03 DIO status,
bit 3).
1073938947
DIO5 Digital input/output DIO5 (as indicated by 02.03 DIO status,
bit 4).
1074004483
DIO6 Digital input/output DIO6 (as indicated by 02.03 DIO status,
bit 5).
1074070019
Const Bit pointer setting (see Terms and abbreviations on page
102).
-
Pointer
36.20 Boost time Boost time. See parameter 36.19 Boost signal.
00:00:00 …
24:00:00
Boost time. 1 = 1 s
(24:00:00 =
86400)
36.21 Timed func1 Selects which time periods (1…4) are used with timed
function 1. Also determines whether boost is used with timed
function 1.
The parameter is a 16-bit word with each bit corresponding to
a function. Whenever a bit is set to 1, the corresponding
function is in use.
The bits of the binary number correspond to the following
functions:
36.22 Timed func2 Selects which time periods (1…4) are used with timed
function 2. Also determines whether boost is used with timed
function 2.
The parameter is a 16-bit word with each bit corresponding to
a function. Whenever a bit is set to 1, the corresponding
function is in use.
The bits of the binary number correspond to the following
functions:
No. Name/Value Description FbEq
Bit Function
0 Timer1 ena (Time period 1 enable)
1 Timer2 ena (Time period 2 enable)
2 Timer3 ena (Time period 3 enable)
3 Timer4 ena (Time period 4 enable)
4 Boost ena (Boost enable)
Bit Function
0 Timer1 ena (Time period 1 enable)
1 Timer2 ena (Time period 2 enable)
2 Timer3 ena (Time period 3 enable)
3 Timer4 ena (Time period 4 enable)
4 Boost ena (Boost enable)
