238 Parameters
Drive name Shows the drive name. (The drive name can be set using the
DriveStudio PC tool.)
2
Drive type Shows the drive type. 3
56.05 Signal2 mode Defines the way the signal selected by parameter 56.02
Signal2 param is displayed on the optional control panel.
Disabled Signal not displayed. Any other signals that are not disabled
are shown together with their respective signal name.
-1
Normal Shows the signal as a numerical value followed by unit. 0
Bar Shows the signal as a horizontal bar. 1
Drive name Shows the drive name. (The drive name can be set using the
DriveStudio PC tool.)
2
Drive type Shows the drive type. 3
56.06 Signal3 mode Defines the way the signal selected by parameter 56.03
Signal3 param is displayed on the optional control panel.
Disabled Signal not displayed. Any other signals that are not disabled
are shown together with their respective signal name.
-1
Normal Shows the signal as a numerical value followed by unit. 0
Bar Shows the signal as a horizontal bar. 1
Drive name Shows the drive name. (The drive name can be set using the
DriveStudio PC tool.)
2
Drive type Shows the drive type. 3
56.07 Local ref unit Defines how speed reference is entered and displayed by the
optional control panel and DriveStudio PC tool. Also
determines the unit of signal 02.34 Panel ref.
Note: This parameter also applies to external control when
speed reference is given from the control panel.
rpm Speed reference is displayed and entered in rpm. 0
Percent Speed reference is displayed and entered in percent. The
scaling is as follows:
1
56.08 Speed filt time Defines a filter time constant for 01.40 Speed filt. A longer
time constant makes the filtered result more steady, but slows
down the reaction to fast speed changes. Compare to
parameter 19.03 MotorSpeed filt.
0.0...10000.0 ms Speed filter time constant. 10 = 1 ms
56.09 Torque filt time Defines a filter time constant for 01.41 Torque filt. A longer
time constant makes the filtered result more steady, but slows
down the reaction to fast speed changes.
0.0...10000.0 ms Torque filter time constant. 10 = 1 ms
No. Name/Value Description FbEq
20.01 Maximum speed
0%
Control panel
reference
Speed (rpm)
100%
-100% 20.02 Minimum speed
0
