248 Parameters
FEN-01 TTL Communication active. Module type: FEN-01 TTL Encoder
Interface. Input: TTL encoder input (X31).
2
FEN-11 ABS Communication active. Module type: FEN-11 Absolute
Encoder Interface. Input: Absolute encoder input (X42).
3
FEN-11 TTL Communication active. Module type: FEN-11 Absolute
Encoder Interface. Input: TTL encoder input (X41).
4
FEN-21 RES Communication active. Module type: FEN-21 Resolver
Interface. Input: Resolver input (X52).
5
FEN-21 TTL Communication active. Module type: FEN-21 Resolver
Interface. Input: TTL encoder input (X51).
6
FEN-31 HTL Communication active. Module type: FEN-31 HTL Encoder
Interface. Input: HTL encoder input (X82).
7
90.02 Encoder 2 sel Activates the communication to the optional encoder/resolver
interface 2.
Note: The counting of shaft revolutions is not supported for
encoder 2.
None Inactive. 0
FEN-01 TTL+ See parameter 90.01 Encoder 1 sel.1
FEN-01 TTL See parameter 90.01 Encoder 1 sel.2
FEN-11 ABS See parameter 90.01 Encoder 1 sel.3
FEN-11 TTL See parameter 90.01 Encoder 1 sel.4
FEN-21 RES See parameter 90.01 Encoder 1 sel.5
FEN-21 TTL See parameter 90.01 Encoder 1 sel.6
FEN-31 HTL See parameter 90.01 Encoder 1 sel.7
90.04 TTL echo sel Enables and selects the interface for the TTL encoder signal
echo.
Note: If encoder emulation and echo are enabled for the
same FEN-xx TTL output, the emulation overrides the echo.
Disabled No echo interface enabled. 0
FEN-01 TTL+ Module type: FEN-01 TTL Encoder Interface. Echo: TTL
encoder input (X32) pulses are echoed to the TTL output.
1
FEN-01 TTL Module type: FEN-01 TTL Encoder Interface. Echo: TTL
encoder input (X31) pulses are echoed to the TTL output.
2
FEN-11 TTL Module type: FEN-11 Absolute Encoder Interface. Echo: TTL
encoder input (X41) pulses are echoed to the TTL output.
3
FEN-21 TTL Module type: FEN-21 Resolver Interface. Echo: TTL encoder
input (X51) pulses are echoed to the TTL output.
4
FEN-31 HTL Module type: FEN-31 HTL Encoder Interface. Echo: HTL
encoder input (X82) pulses are echoed to the TTL output.
5
90.05 Enc cable fault Selects the action in case an encoder cable fault is detected
by the FEN-xx encoder interface.
No Cable fault detection inactive. 0
Fault The drive trips on an ENCODER 1/2 CABLE fault. 1
No. Name/Value Description FbEq
