308 Fault tracing
0209 STACK ERROR
(0x6100)
Drive internal fault
Note: This fault cannot be
reset.
Contact your local ABB representative.
0210 JMU MISSING
(0xFF61)
JMU Memory Unit is missing or
broken.
Check that the JMU is properly installed.
If the problem persists, replace the JMU.
0301 UFF FILE READ
(0x6300)
File read error
Note: This fault cannot be
reset.
Contact your local ABB representative.
0302 APPL DIR CREATION
(0x6100)
Drive internal fault
Note: This fault cannot be
reset.
Contact your local ABB representative.
0303 FPGA CONFIG DIR
(0x6100)
Drive internal fault
Note: This fault cannot be
reset.
Contact your local ABB representative.
0304 PU RATING ID
(0x5483)
Drive internal fault
Note: This fault cannot be
reset.
Contact your local ABB representative.
0305 RATING DATABASE
(0x6100)
Drive internal fault
Note: This fault cannot be
reset.
Contact your local ABB representative.
0306 LICENSING
(0x6100)
Drive internal fault
Note: This fault cannot be
reset.
Contact your local ABB representative.
0307 DEFAULT FILE
(0x6100)
Drive internal fault
Note: This fault cannot be
reset.
Contact your local ABB representative.
0308 APPLFILE PAR
(0x6300)
Corrupted application file
Note: This fault cannot be
reset.
Reload application.
If fault is still active, contact your local
ABB representative.
0309 APPL LOADING
(0x6300)
Application file incompatible or
corrupted
Note: This fault cannot be
reset.
Check the fault logger for a fault code
extension. See appropriate actions for
each extension below.
*Refer to Application programming for
ACS850 drives (3AUA0000078664
[English]).
Extension: 8 Template used in the
application incompatible with
drive firmware.
*Change the template of the application
in DriveSPC.
Extension: 10 Parameters defined in the
application conflict with
existing drive parameters.
*Check the application for conflicting
parameters.
Extension: 35 Application memory full. Contact your local ABB representative.
Extension: Other Corrupted application file *Reload application.
If fault is still active, contact your local
ABB representative.
Code Fault
(fieldbus code)
Cause What to do
