5.5 ANALOG OUTPUT MODULES (AO0-3)
The Analog Output Modules (AO0-3) are used to configure the characteristics of each output. Outputs AO2 and AO3 are active only if
the appropriate hardware option is installed. The four Analog Output Modules are provided in Table 5-5. Each one can be configured
separately.
Table 5-5. Analog Output Modules (AO0-3)
Title Definition Atom AO0 AO1 AO2 AO3 Default
Analog Output The value in this datapoint represents
the percent of output to be generated by
hardware (e.g., 100% output = 20 mA).
AO
(0-3)
C000 C001 C002 C003 0
Signal Base This value specifies the signaling range
of the output:
0
- 4-20 mA
1
- 0-20 mA
BASE
(0-3)
L472 L473 L474 L475 0
Calibrate Zero This is the calibration zero adjustment.
This parameter
is factory set
and
should not need adjustment
under
normal operation. See Section 18.4 for
additional information.
COZ
(0-3)
B267 B268
Calibrate Span This is the calibration span adjustment.
This parameter
is factory set
and
should not need adjustment
under
normal operation. See Section 18.4 for
additional information.
COS
(0-3)
C300 C301
Tag Name It is an assignable 10 character name for
the analog output (AO0).
TAG A244 A245 A246 A247
5-8
53MC5000 Process Control Station
