ABB ControlIT 53MC5000 User Manual

Table 5-9. Controller Modules (CON0-3)
Title Definition Atom CON0 CON1 CON2 CON3 Default
Setpoint Mode This parameter specifies how the setpoint
increase and decrease push buttons function
when the controller is in remote:
0
- STD (push buttons have no effect).
1
- K-SP (push buttons adjust Remote Setpoint
Ratio, K1 - C113, etc.).
2
- B-SP (push buttons adjust Remote Setpoint
Bias, B1 - C112, etc.).
SPM
(0-3)
B338 B343 B348 B353 0
Control Display Mode This parameter controls the type of point
display that is used with the CON module.
0
- STD (Standard PID).
1
- IND (Indicator).
2
- LDR (Manual Loader).
3
- RCTRL (Ratio Controller).
4
- SEL (Automatic/Manual Station).
5
- RSEL (Ratio Automatic/Manual Station).
CDM
(0-3)
B339 B344 B349 B354 0
SP Track Status
1
indicates the setpoint comes from Setpoint
Track Value (STV).
0
indicates the setpoint
comes from the setpoint push buttons or is a
Remote Setpoint (RSP) dependent on the
value of Remote Status (RMT).
SPTS
(0-3)
L104 L128 L152 L176 0
Output Track Status
1
indicates the output comes from the Output
Track Value (OTV). A
0
indicates the output
comes from the output push buttons or the
Control Output (CO). Output Track Status is
dependent on the value of Auto Status (AUT).
OVTS
(0-3)
L105 L129 L153 L177 0
Reverse Switch
0
- DIR (When set to a
0
, the controller output
increases as the process variable increases).
1
- REV (When set to a
1
, the controller output
decreases as the process variable increases).
RSW
(0-3)
L106 L130 L154 L178 1
3 of 9
5-16
53MC5000 Process Control Station
