Table 5-9. Controller Modules (CON0-3)
Title Definition Atom CON0 CON1 CON2 CON3 Default
Auto Status When Output Track Status (OVTS) is
0
,
1
indicates Control Output (CO) is selected as
the output.
0
indicates the output comes from
the output push buttons.
AUT
(0-3)
L107 L131 L155 L179 0
Remote Status When the Setpoint Track Status (SPTS) is
0
,
1
indicates the setpoint is derived from the
Remote Setpoint (RSP).
0
indicates it comes
from the setpoint push buttons.
RMT
(0-3)
L108 L132 L156 L180 0
Reverse Valve This parameter specifies the location of
Open/Close indicators in the control display.
1
means that 20 mA closes the valve.
0
indicates that 20 mA opens the valve.
RSV
(0-3)
L109 L133 L157 L181 0
Alarm A Active See Control Alarm Mode (AIX). PA1
(0-3)
L110 L134 L158 L182 0
Alarm B Active See Control Alarm Mode (AIX). PA2
(0-3)
L111 L135 L159 L183 0
Auto Switch This parameter is used in conjunction with
Auto Enable (AE) to allow the Control Output
(OUT) to become the auto/manual generator
result Output (OUT).
SWA
(0-3)
L112 L136 L160 L184 0
Remote Switch This parameter is used in conjunction with
Remote Setpoint Enable (RE) to allow the
modified Remote Setpoint to become the
setpoint value to the setpoint generator.
SWR
(0-3)
L113 L137 L161 L185 0
Auto Enable When this parameter is set to a
1
, the Control
Output (CO) becomes the auto/manual
generator result Output (OUT) if the Auto
Switch (SWA) is set to a
1
by the A/M push
button or user program (F-TRAN, FCIM, or
FCS wire list).
AE
(0-3)
L114 L138 L162 L186 1
4 of 9
5-17
Section 5. Configuration Parameters
