Table 5-10. Status Modules (SDT0 and SDT1)
Title Definition Atom SDT0 SDT1 Default
Modify Disable 0 When set to a
1
, this parameter inhibits the operator
from modifying the state of the corresponding individual
points with the push buttons. (The arrow indicator on
the SDT display skips over the inhibited points when the
up/down faceplate push buttons are pressed.)
When set to a
0
, the operator can alter the state of the
individual corresponding points with the push buttons.
0
- NO
1
- YES
SDA L320 L328 0
Modify Disable 1 SDB L321 L329 0
Modify Disable 2 SDC L322 L330 0
Modify Disable 3 SDD L323 L331 0
Modify Disable 4 SDE L324 L332 0
Modify Disable 5 SDF L325 L333 0
Modify Disable 6 SDG L326 L334 0
Modify Disable 7 SDH L327 L335 0
Display This is the index number for the display that provides
access through the status module.
21 22
4 of 4
5-26
