Table 11-3. CS20 Two Loop Controller Datapoints
Data-
point Table Module Title and Function
De-
fault
AI2 - Remote Setpoint Loop 1 (Is affected by Setpoint Related Datapoints) (Cont)
C112 5-9 CON0 Remote Setpoint Bias (B1) - This datapoint and Remote
Setpoint Ratio (K1) allow the Remote Setpoint input to be
modified by the Setpoint Generator.
Setpoint = [Remote Setpoint X Ratio] + Bias
SP = [RSP X K1] + B1
The B1 and K1 datapoints are modified when the input signal
must be scaled to match the setpoint range desired.
0
C113 5-9 CON0 Remote Setpoint Ratio (K1) - See Remote Setpoint bias (B1)
above.
1
C258 5-4 AI2 Engineering Span - Enter a value, that when added to
Engineering Zero, will produce an upper range value in
engineering units that represents the Loop 1 Remote
Setpoint upper range signal value.
0
C278 5-4 AI2 Engineering Zero - Enter a value that represents in
engineering units the Loop 1 Remote Setpoint lower range
signal value.
0
B271 5-4 AI2 Digital Filter Index - This is a first order filter that can be
applied to the Loop 1 Remote Setpoint signal. See Table 5-4
for input values.
3
L418 5-4 AI2 0-5 V Input - Enter a value that matches the signal voltage
range of the Loop 1 Remote Setpoint signal. 1 = 0 - 5 V
input range; 0 = 1 - 5 V input range.
0
L442 5-4 AI2 Square Root Signal - It is used if the Loop 1 Remote Setpoint
input is a squared signal value that must be linearized. 0 =
input is already linear; 1 = square root to restore linearization.
0
AI3 - Remote Setpoint Loop 2 (Is affected by Setpoint Related Datapoints)
L139 5-9 CON1 Remote Setpoint Enable - This datapoint is controlled by DI1.
When DI1 is a closed contact, this datapoint is set to 1 to
allow the modified Loop 2 Remote Setpoint to become the
value used as the control setpoint if the R/L push button is in
Remote.
0
C148 5-9 CON1 Remote Setpoint Bias (B1) - This datapoint and Remote
Setpoint Ratio (K1) allow the Remote Setpoint input to be
modified by the Setpoint Generator.
Setpoint = [Remote Setpoint X Ratio] + Bias
SP = [RSP X K1] + B1
The B1 and K1 datapoints are modified when the input signal
must be scaled to match the setpoint range desired.
0
C149 5-9 CON1 Remote Setpoint Ratio (K1) - See Remote Setpoint bias (B1)
above.
1
C259 5-4 AI3 Engineering Span - Enter a value, that when added to
Engineering Zero, will produce an upper range value in
engineering units that represents the Loop 2 Remote
Setpoint upper range signal value.
0
2 of 6
Section 11. CS20 - Two Loop Controller
11-7
