Table 1-1. 53MC5000 Process Control Station Specifications
Item Specification(s)
Enclosure classification/environment
(cont)
Rated for installation in a "Pollution Degree 2" location per
U.L. 508-1989/"Controlled Environment" per CSA C22.2 No.
142-M1987. An indoor, temperature controlled location
(control room or shop floor) where normally, only non-
conductive pollution occurs; however, temporary
conductivity caused by condensation may be expected.
Location in environments more severe than the above
requires supplementary protection.
Shock vibration 0.5 g, ISA, G3.
Vibration SAMA PMC 31.1-1978; point to point constant displacement
0.05" (1.27mm), 5 to 14 Hz: 0.5 g, 14 to 200 Hz.
Drop and topple SAMA PMC 31.1-1978; Tilt 30 degrees from horizontal and
fall freely to a hard surface, all sides, front and back.
Safety classification A) General Purpose: Complies with ANSI/ISA S82.01-1988,
Safety Standard for Electrical and Electronic Test,
Measuring, Controlling and Related Equipment; General
Requirements and S82.03-1988 Safety Standard for
Electrical and Electronic Test, Measuring, Controlling and
Related Equipment; Electrical and Electronic Process
Measurement and Control Equipment.
B) FM Approved: Nonincendive for Class I, Div 2, Groups
A, B, C & D hazardous locations.
Physical characteristics:
Construction materials:
Case
Circuit boards
Bezel
Instruments dimensions
Steel, ABB Light Gray enamel.
Glass epoxy.
ULTEM 1000
®
(Polyetherimide Resin) Flammability-UL94
5V.
2.844 W x 5.656 H x 12.906 L (inches)
73 W x 144 H x 329 L (mm)
Flush panel mounting 0.125 inch to 1 inch thickness (3.2mm to 25.4mm).
Electrical connections Rear of case screw type terminal block.
Weight (approximate) 5 pounds (2.3 kg).
PID control ranges:
Proportional band
Integral
Derivative
2% to 1000% and
off
.
0.02 to 200 min./repeat, or Manual Reset from 0 to 100%.
0.01 to 8 minutes advanced and
off
.
Front panel:
Display - High Resolution
- Low Resolution
Push buttons
192 x 96 dot matrix addressable.
96 x 48 dot matrix addressable.
10 membrane type switches.
