ABB ControlIT 53MC5000 User Manual

Table 15-3. CS41 Four Loop Controller Datapoints
Data-
point Table Module Title and Function
De-
fault
CON2 Control Loop 3 Related Datapoints (Cont)
C183 5-9 CON2 Manual Reset - It determines Loop 3 output valve position
when the controller is in Auto and the error = 0. It is mutually
exclusive with Reset Time.
50
L154 5-9 CON2 Reverse Switch - 0 = Loop 3 Control Output
↑
if Loop 3 PV
↑
; 1 = Loop 3 Control Output
↓
if Loop 3 PV
↑
.
1
L162 5-9 CON2 Auto Enable - Controller output is from the Loop 3 PID
algorithm when set to 1 and A/M push button is in Auto.
1
C187 5-9 CON2 Controller Span - Enter a value, that when added to the Loop
3 Controller Lower Range value, will produce the Loop 3
control upper range value in engineering units.
100
C188 5-9 CON2 Controller Lower Range - Enter a value that represents in
engineering units the Loop 3 control lower range value.
0
AO3 - Control Output Loop 4
L475 5-5 AO3 0-20 mA Output - 0 = 4-20 mA signal; 1 = 0-20 mA signal.
Enter a value to match the Loop 4 output valve requirements.
0
L192 5-9 CON3 Manual Fallback Disable - 0 = always power up in manual for
Loop 4; 1 = auto/manual selector unchanged at power up.
0
L194 5-9 CON3 Hard Manual Limit - 1 = apply output limits to the final output
of the Loop 4 Auto-Manual Generator. Affects both the
manual push buttons and the controller’s result. 0 = do not
apply limits.
1
C217 5-9 CON3 Output High Limit - Sets maximum Loop 4 Control Output
signal value in engineering units.
100
C218 5-9 CON3 Output Low Limit - Sets minimum Loop 4 Control Output
signal value in engineering units.
0
C226 5-9 CON3 Output Slew Rate - It is a rate limit applied to the output
value. When configured to a non-zero value, the output from
the Loop 4 Auto-Selector is only allowed to change by this
amount each scan time. A zero disables output slewing. It
does not affect manual operation.
0
CON3 Control Loop 4 Related Datapoints
C214 5-9 CON3 Proportional Band - Is the Loop 4 percent of error required to
move the output full scale for proportional action.
100
C215 5-9 CON3 Reset Time - Is the number of minutes per repeat of integral
action for Loop 4. It is mutually exclusive with Manual Reset.
0
C216 5-9 CON3 Rate Time - Represents the minutes Loop 4 proportional
action is advanced.
0
C219 5-9 CON3 Manual Reset - It determines the Loop 4 output valve
position when the controller is in Auto and the error = 0. It is
mutually exclusive with Reset Time.
50
L178 5-9 CON3 Reverse Switch - 0 = loop 4 Control Output
↑
if Loop 4 PV
↑
;
1 = Loop 4 Control Output
↓
if Loop 4 PV
↑
.
1
L186 5-9 CON3 Auto Enable - Controller output is from the Loop 4 PID
algorithm when set to 1 and A/M push button is in Auto.
1
8 of 13
53MC5000 Process Control Station
15-16
