Table D-16. Database - C Type Datapoints
Data-
point
Name Module Atom Default Table
C146 Output Low Limit
Controller 1
OL1 0
5-9
C147 Manual Reset MR1 50
C148 Remote SP Bias B11 0
C149 Remote SP Ratio K11 1
C150 Control Zone CZ1 0
C151 Controller Span IR1 100
C152 Controller Lower Range ILR1 0
C153 Setpoint Slew Rate T11 0
C154 Output Slew Rate T31 0
C155 Control Setpoint TSP1 0
C156 Remote Setpoint RSP1 0
C157 Deviation DV1 0
C158 Feed Forward FF1 0
C159 Control Output CO1 0
C160 Partial Output Term PN1 0
C161 Setpoint High Limit SH1 100
C162 Setpoint Low Limit SL1 0
C163 Reset Feedback RF1 0
C164 Setpoint Track Value STV1 0
C165 Output Track Value OTV1 0
C166-
C171
Reserved
C172 Process Variable
Controller 2
PV2 0
5-9
C173 Setpoint SP2 0
C174 Output OUT2 0
C175 Alarm Limit 1 PL12 100
C176 Alarm Limit 2 PL22 0
C177 Alarm Dead Band ADB2 2
C178 Proportional Band PB2 100
C179 Reset Time TR2 0
C180 Rate Time TD2 0
C181 Output High Limit OH2 100
C182 Output Low Limit OL2 0
C183 Manual Reset MR2 50
C184 Remote SP Bias B12 0
C185 Remote SP Ratio K12 1
C186 Control Zone CZ2 0
C187 Controller Span IR2 100
C188 Controller Lower Range ILR2 0
C189 Setpoint Slew Rate T12 0
C190 Output Slew Rate T32 0
C191 Control Setpoint TSP2 0
3 of 7
Appendix D. Database
D-25
