Table D-16. Database - C Type Datapoints
Data-
point
Name Module Atom Default Table
C192 Remote Setpoint
Controller 2
RSP2 0
5-9
C193 Deviation DV2 0
C194 Feed Forward FF2 0
C195 Control Output CO2 0
C196 Partial Output Term PN2 0
C197 Setpoint High Limit SH2 100
C198 Setpoint Low Limit SL2 0
C199 Reset Feedback RF2 0
C200 Setpoint Track Value STV2 0
C201 Output Track Value OTV2 0
C202-
C207
Reserved
C208 Process Variable
Controller 3
PV3 0
5-9
C209 Setpoint SP3 0
C210 Output OUT3 0
C211 Alarm Limit 1 PL13 100
C212 Alarm Limit 2 PL23 0
C213 Alarm Dead Band ADB3 2
C214 Proportional Band PB3 100
C215 Reset Time TR3 0
C216 Rate Time TD3 0
C217 Output High Limit OH3 100
C218 Output Low Limit OL3 0
C219 Manual Reset MR3 50
C220 Remote SP Bias B13 0
C221 Remote SP Ratio K13 1
C222 Control Zone CZ3 0
C223 Controller Span IR3 100
C224 Controller Lower Range ILR3 0
C225 Setpoint Slew Rate T13 0
C226 Output Slew Rate T33 0
C227 Control Setpoint TSP3 0
C228 Remote Setpoint RSP3 0
C229 Deviation DV3 0
C230 Feed Forward FF3 0
C231 Control Output CO3 0
C232 Partial Output Term PN3 0
C233 Setpoint High Limit SH3 100
C234 Setpoint Low Limit SL3 0
C235 Reset Feedback RF3 0
C236 Setpoint Track Value STV3 0
C237 Output Track Value OTV3 0
