ABB ControlIT 53MC5000 - Page 378

Table D-16. Database - C Type Datapoints
Data-
point
Name Module Atom Default Table
C238-
C243
Reserved
C244-
C249
Reserved Temporaries
BCTEMP
1 - 6
0
C250-
C255
Reserved Temporaries
FCTEMP
1 - 6
0
C256 AI0 Engineering Span
AI
SPAN0 100
5-4
C257 AI1 Engineering Span SPAN1 0
C258 AI2 Engineering Span SPAN2 0
C259 AI3 Engineering Span SPAN3 0
C260 AI4 Engineering Span SPAN4 0
C261 AI5 Engineering Span SPAN5 0
C262 AI6 Engineering Span SPAN6 0
C263 AI7 Engineering Span SPAN7 0
C264 AI8 Engineering Span SPAN8 0
C265-
C275
AI9 through AI19 Engineering Spans
SPAN9-
SPAN19
0
C276 AI0 Engineering Zero
AI
ZERO0 0
5-4
C277 AI1 Engineering Zero ZERO1 0
C278 AI2 Engineering Zero ZERO2 0
C279 AI3 Engineering Zero ZERO3 0
C280 AI4 Engineering Zero ZERO4 0
C281 AI5 Engineering Zero ZERO5 0
C282 AI6 Engineering Zero ZERO6 0
C283 AI7 Engineering Zero ZERO7 0
C284 AI8 Engineering Zero ZERO8 0
C285-
C295
AI9 through AI19 Engineering Zeros
ZERO9-
ZERO19
0
C296 AI0 Calibrate Span (Standard)
AI
CIS0
5-4
C297 AI1 Calibrate Span (Standard) CIS1
C298 AI2 Calibrate Span (Standard) CIS2
C299 AI3 Calibrate Span (Standard) CIS3
C300 AO0 Calibrate Span (Standard)
AO
COS0
5-5
C301 AO1 Calibrate Span (Standard) COS1
C302 Trend 0 Zero
Trend
TRZ0 0
5-12
C303 Trend 0 Span TRS0 0
C304 Trend 1 Zero TRZ1 0
C305 Trend 1 Span TRS1 0
C306 Trend 2 Zero TRZ2 0
C307 Trend 2 Span TRS2 0
C308 Trend 3 Zero TRZ3 0
C309 Trend 3 Span TRS3 0
C310 Trend 4 Zero TRZ4 0
5 of 7
Appendix D. Database
D-27
