9 Spare part list
9.0.2 Manipulator complete
3HAC021111-001 Revision: B 163
150 4 Tapping screw 2121 2477-291 M4x12
151 1 Bracket SK 616 013-F
152 1 Actuator 1SFA616100R1006 Black
154 1 Protective cover 1SFA616920R8010
156 1 Sealing 3HAB 3293-1
159 11 Straps (outdoor) 2166 2055-1 L=92 mm
160 46 Tapping screw 9ADA 624-44 M5x12
161 1 Dust cap 5217 649-9 12p. FCI
162 1 Gasket 2152 0363-3 12p. FCI
163 1 Cable guide 3HAB 3328-1
164 1 Profile 1866 1903-1 L=100
165 1 Ta pe 1169 9198-301 L=200
167 7 Screw 9ADA 129-45 M5x16
170 2 Protective hood 2522 2101-8 D=11.1 - 13
Option 041
171 12 Nut 9ADA 290-1 M5
172 1 Cable pos. indicator axis
1
HAB 3310-1 Option 075
173 2 Bushing 2166 2421-2 Option 075
174 2 Limit switch 3HAA 2496-1 Option 075
175 1 Protective hood 3HAB 9344-1 Option 042
176 2 Dust cap 5217 649-9 Option 041 or 042
177 1 Dust cap 5217 649-9 Option 075
179 1 Sealing liquid 1269 0014-412 Loctite 542, option 041
180 1 Coupling 3HAB 3333-20 Option 041
181 2 Cable gland 2672 063-3 Pr 18.6, option 075
182 2 Rubber washer 2452 398-2 Pr 18.6, option 075
184 1 Protective hood 2522 726-3 D=7.6-9.3, option 059
186 1 Protective hood 2522 2101-9 D=12-13.9
187 2 Protective hood 2522 2101-9 D=12-13.9
188 1 Cover 3HAB 9343-1
189 3 Adaptor power cabling 3HAC 2809-1
190 16 Screw 9ADA 629-22 M3x6
192 4 Screw 9ADA 629-22 M3x6
193 4 Nut 9ADA 267-6 M6
194 1 Gasket 3HAB 7195-1
196 1 Cover plate 3HAC 2056-1 Option 041
197 1 Dust cap 3HAA 1001-630 Option 042
Item Qty Name Art. no. Remark
