9 Spare part list
9.0.2 Manipulator complete
162 3HAC021111-001 Revision: B
71 1 Shaft 3HAB 3256-1
72 1 Spacer 3HAB 3264-1 M5x140
73 1 Washer 3HAA 2355-11
74 1 Screw 9ADA 183-36 MC6S, M8x20
75 1 Sealing washer 3HAB 3767-1
76 2 Nut 9ADA 267-8 M10
101 1 Bracket 3HAB 3225-1
102 1 Bracket 3HAB 9387-1
103 1 Spring 3HAB 3291-1
104 1 Cable guide 3HAB 3298-1
105 2 Holder for cable guide 3HAB 3299-1
106 1 Cable unit axes 1-3 3HAB 8440-1
107 1 Cable unit axes 4-6 3HAC 1855-1 Option 040
+ standard
107 1 Cable unit axes 4-6 3HAC 1856-1 Option 041
+ standard
107 1 Cable unit axes 4-6 3HAC 1857-1 Option 040
+ hanging
107 1 Cable unit axes 4-6 3HAC 1858-1 Option 041
+ hanging
107 1 Cable unit axes 4-6 3HAC 2072-1 Option 042
+ standard
109 2 Bracket, axes 5-6 3HAB 3230-1
110 1 Clamp 2166 2018-2 D=11
111 1 Clamp 2166 2018-8 D=6
117 3 Cover, axes 1-3 3HAC 4337-1
119 3 Gasket 3HAC 4419-1
122 1 Cover, axis 4 3HAC 4350-1 Not option 691
122 1 Lamp unit 3HAC 2743-1 Option 691
124 3 Gasket 3HAC 4429-1
127 1 Cover, axes 5-6 3HAC 4405-1
130 1 Battery unit 4944 026-4
135 1 SMB with bracket 3HAB3700-1
136 1 Signal cable SMB 3HAB 3774-1
137 1 Gasket 3HAB 3348-1
138 1 Bracket 3HAC 2037-1
139 1 Earth symbol 3HAB 5617-1
140 2 Clamp 2166 2018-7 D=5
144 12 Straps (outdoor) 2166 2055-3 L=186 mm
145 4 Straps (outdoor) 2166 2055-6 L=386 mm
147 6 Tapping screw 9ADA 624-47 M5x25
148 4 Screw 9ADA 183-22 M6x10
149 8 Screw 9ADA 183-11 M5x8
Item Qty Name Art. no. Remark
