Installing the control cabinet
Risk of injury in the area of the gas sampling system due to moving or fall-
ing parts, hot surfaces, anti-freeze, compressed air, lubricating oil
Wear general personal protective equipment:
 Closed overalls with long trousers and long sleeves
 Safety shoes
 Safety gloves suitable for mechanical work
 Safety glasses
 Protective helmet
 If necessary, additional protective equipment if prescribed by the opera-
tor.
Danger of crushing when lifting or lowering the transport unit
 Only appropriately trained personnel may transport the transport units and
only with the aid of the recommended transport equipment.
 Do not stand under suspended loads.
 Follow the transport instructions in these operating instructions care-
fully.
 4 galvanized steel screws (or stainless material) M10 or bolts M10
The following requirements must be met in order to install the control cabi-
net:
 The site conforms to the designated site conditions (criteria see Choosing
the place of installation of the peripheral modules ).
 Fastening points are present to affix the control cabinet.
 The control cabinet is unpacked.
How to install the control cabinet:
Step Procedure
1
Fasten control cabinet in suitable position (see Choos-
ing the place of installation of the control cabinet ) with 4
assembly screws or bolts.
Mechanical, thermal
and material dangers
Heavy transport
units
Screws required for
assembly
Requirements
Instructions
