ABB SCK - Handling Error Messages

OI/SCK
-EN Rev. E Operating instruction SCK Gas Sampling System 223
Handling error messages
Always take the following safety measures when performing this work:
 Wear the general protective equipment.
 Before commencing any work on the gas sampling system, turn the ser-
vice switch to ON and secure the service switch against unauthorized
switching (with a padlock).
 Additionally press the EMERGENCY-STOP switch before working on the
retractor or probe.
 Do not enter the danger area around the retractor until it is at standstill
and the warning lamps and buzzer are off.
 Never stand in the danger area around the retractor when the protective
installation is closed.
 When the warning lamps light up or the earning buzzer buzzes, leave the
danger area around the probe retractor immediately as the probe is
about to move at any moment.
 Press the EMERGENCY-STOP switch immediately if anyone is still in the
danger area around the retractor after the warning lamps light up or the
warning buzzer buzzes.
Explanation of safety measures: Safety regulations for maintenance work on
page 158.
In the event of an error, the probe is automatically retracted out of the kiln
until the probe reaches its end position. To make sure that it really has
reached its end position and that no unexpected probe movement can be
expected, wait for the warning lamps on the retractor terminal box to go out
before fixing the errors.
Proceed as follows to fix errors:
Step
Procedure
1
Turn service switch to ON position.
When working on the retractor and gas sampling probe, addi-
tionally actuate the EMERGENCY-STOP switch for reasons of
safety.
2
Fix errors.
DANGER! Fixing errors requires special training and involves
working on the open and powered-on gas sampling system.
Therefore this may only be carried out by qualified and specially
trained personnel.
3
Turn service switch to OFF position.
4
In controller: insert the probe.
Path: Operation ► Probe ► Probe Action ► Insert
WARNING! The probe moves into the kiln. Do not stand in the
area of travel of the probe or probe carriage.
5
In controller: switch gas sampling system to Automatic mode.
Path: Operation ► Automatic on / off
Safety
measures
Requirements
Instructions
